● Hex bolts are a type of threaded bolt, characterised by their six-sided hexagonal-shaped head. Hex bolts can be either fully threaded or partially threaded and are suitable for use in a wide range of applications, typically machinery and construction.
● We support customized and can also manufacture non-standard fasteners according to your drawings.
Series |
Half Thread (Partial Thread) , Full Thread. |
Standard |
DIN, ASTM/ANSI, JIS, ISO, GB and so on. |
Metric |
Dia M5 - M16 & Lengths 10mm - 140mm |
Threads |
Metric Coarse & Fine |
Strength |
Property Class 4.8, 8.8, 10.9, 12.9 |
Material |
Q195, 35K, 10B21,40Cr, 35CrMo |
Surface Treatment |
Plain, Zinc Plated & Zinc Yellow, Blackening, Ni Plated |
Application |
|
19-09-2023
Wholesale High Quality nuts and bolts Manufacturers in China High Quality nuts and bolts are essential hardware items that are widely used in various industries. They play a crucia...
17-09-2023
Supply OEM/ODM hex head bolts hexagon socket head bolts Company In the vast world of fasteners, OEM/ODM hex head bolts and hexagon socket head bolts Company hold their distinct pla...
15-09-2023
Hot Sale OEM/ODM screw nuts Manufacturers in China In the realm of mechanical engineering, the humble screw nut plays a paramount role that belies its simplicity. As an essential f...
08-09-2023
Supply High Quality OEM/ODM flange bolts Manufacturers What are the Different Types of Flange Screws? Flange screws, also known as OEM/ODM flange bolts, are widely used in various ...
The difference between a partially threaded Hex Head Bolt and a fully threaded one lies in the extent to which the threading extends up the length of the shank. The threading on a Hex Head Bolt refers to the spiral grooves that are cut into the length of the bolt to allow it to be screwed into a threaded hole or nut.
In Hex Head Bolts, the threading can extend partially up the shank, or it can extend the entire length of the shank. A partially threaded Hex Head Bolt typically has threading that only extends up to a certain point on the shank, usually stopping before it reaches the head of the bolt. Conversely, a fully threaded Hex Head Bolt has threading that extends the entire length of the shank, all the way up to the underside of the head.
The choice between partially threaded and fully threaded Hex Head Bolts depends on the application in question. In some cases, it may be desirable to use a partially threaded bolt in order to provide a certain amount of space between the underside of the bolt head and the component being fastened. This spacing may be necessary in order to allow for the use of a nut or washer beneath the head of the bolt. In other instances, a partially threaded bolt may be preferable when the application requires a certain amount of flexibility or movement between the components being fastened.
On the other hand, fully threaded Hex Head Bolts can offer additional clamping force and stability when securing components tightly together. This is because the threading runs the entire length of the shank, allowing the bolt to engage directly with the component being fastened, and providing additional surface area for the application of torque when tightening the bolt. Fully threaded Hex Head Bolts are typically used in applications where the components being fastened need to be held tightly together, and movement or flexibility is not required.
When installing hex head bolts, it is essential to determine the correct torque to apply to ensure proper tightening and avoid any potential issues with the connection. Several factors need to be considered when determining the appropriate torque for hex head bolts:
(1)Thread size and pitch: The thread size and pitch of the bolt play a significant role in determining the torque. Larger bolts with coarser threads require more torque to achieve the same level of tightness compared to smaller bolts with finer threads.
(2)Material: The material of the bolt and the material of the mating surfaces must be considered when determining the torque. The type of material can affect the frictional forces between the bolt and the surfaces, which, in turn, affects the required torque.
(3)Lubrication: The use of lubrication can significantly affect the required torque. Lubricants can reduce the frictional forces and, in turn, reduce the required torque. It is essential to use the correct type and amount of lubricant to avoid over or under-tightening the bolts.
(4)Bolt length: The length of the bolt also plays a role in determining the torque required. Longer bolts require more torque to achieve the same level of tightness compared to shorter bolts.
(5)Environmental factors: The environment in which the bolt is installed can affect the required torque. Factors such as temperature, humidity, and vibration can all impact the torque required for proper tightening.
